| 1 | MEMORY | 99 PROGRAMS’ STORAGE |
| 2 | TURN SET EACH PROGRAMMES | 999 MAX TURNS |
| 3 | PRODUCTION COUNT | PROVIDED |
| 4 | POWER FAIL SAVE | COUNTER WILL NOT RESET |
| 5 | WIRE GAUGES | 30 SWG- 10 SWG –SINGLE/MULTI WIRE CAN WIND |
| 6 | CORE OUTER DIAMETER | 13-50 MM DIAMETERS |
| 7 | CORE INNER DIAMETER | 5 MM-40MM |
| 8 | CORE HEIGHT | 5MM-20 MM |
| 9 | HOOK- UP/DOWN, OPERATING | PNEUMATIC CYLINDER BY FOOT PEDAL MANUALLY |
| 10 | SEGMENT WINDING | PROVIDED 30-360 DEGREE, PROGRAMMABLE |
| 11 | WINDING PITCH ADJUST | PROVIDED ONLINE |
| 12 | EVERY LAYER STOP | ONLINE- SWITCH PROVIDED |
| 13 | DISPLAY | 20X4 COLOUR LCD DISPLAY |
| 14 | CORE FIXING ROLLERS | RUBBER MOULDED ROLLERS |
| 15 | SUPPLY | 220V 50HZ 1 Phase |
| 16 | WINDING SPEED | DEPENDS ON THE OPERATOR SPEED MAX 30 RPM |
| 17 | TOTAL TAPS | 8 TAPS EACH PROG PROVIDED |
| 18 | CORE INDEX MOTOR | HYBRID STEPPER MOTOR WITH DRIVE |
| 19 | ONLINE CORE ADJUSTMENT | ONLINE SWITCH PROVIDED |
| 20 | TURNS INDICATION | ONLINE DISPLAY |
| 21 | CONTROLLER SECURITY | PASSWORD OPTION PROVIDED |
| 22 | MACHINE DIMENSION | |
| 23 | HOOK | STEEL HOOK 8MM DIAMETER |
| 24 | HOOK HOLDER | ADJUSTABLE UPTO 10MM DIAMETER |
| 25 | MACHINE WEIGHT | APPROXIMATLY 80 KGS |
