Technical Specification & Feature
| 1 | Memory | 499 Programs’ Storage |
| 2 | Turn Set Each Programmes | 99.999 Max Turns |
| 3 | Production Count | Provided |
| 4 | Power Fail Save | Counter Will Not Reset |
| 5 | Wire Gauge | 30 Swg- 20 Swg - |
| 6 | Core Outer Diameter (Fod) | 30-120 Mm Diameters |
| 7 | Core Inner Diameter(Fid) | 20 Mm-100mm |
| 8 | Core Height (Fht) | 10mm-50mm |
| 9 | Shuttle Drive Motor | 0.5hpac Motor With Vfd |
| 10 | Segment Winding | Provided 360 Degree |
| 11 | Winding Pitch Adjust | Provided Online |
| 12 | Every Layer Stop | On/Off. Indication Online |
| 13 | Display | 20x4 Colour Lcd Display |
| 14 | Jog Speed | Online Key Provided |
| 15 | Supply | 220v 50hz 1 Phase |
| 16 | Winding Speed | Variable By Up/Down Key |
| 17 | Total Taps | 8 Taps Each Prog Provided |
| 18 | Core Index Motor | Hybrid Stepper Motor |
| 19 | Online Core Adjustment | Switch Provided |
| 20 | Winding Speed | Slider -1800rpm- Belt Type-500rpm |
| 21 | Shuttles Available | 8 .10.12. Extra Cost |
| 22 | De Accelaration | Programmable |
| 23 | Turns Indication | 5turns Accuracy |
| 24 | Controller Security | Password Option Provided |
| 25 | 0.7mm Nylon Sliders | Available On Extra Cost |
