Technical Specifications & Features
| 1 | Total Memory | 1 To 499 Different Programs’ Saving Option Provided |
| 2 | Turn Set Each Programmes | 9.999 Max Turns |
| 3 | Production Count | Provided |
| 4 | Power Fail Save | Counter Will Not Reset |
| 5 | Wire Gauge | 25-10 Swg |
| 6 | Finished Core Outer Diameter | 75 -300 Mm |
| 7 | Finished Core Inner Diameter | 60 Mm- 250 Mm |
| 8 | Finished Core Height | 10mm-150mm |
| 9 | Shuttle Drive Motor | 2 Hp Ac Geared Motor With Vfd |
| 10 | Segment Winding | Provided Upto 360 Degrees |
| 11 | Winding Pitch Adjust | Provided |
| 12 | Total Taps | 8 Taps Each Prog Provided |
| 13 | Display | 20x4 Colour Lcd Display |
| 14 | Jog Speed 01%-20% Provided | Online Key Provided |
| 15 | Wire Loading Speed 120 Rpm | Programmable 0%-99% |
| 16 | Winding Speed 120 Rpm | Programmable 0%-99% |
| 17 | Supply | 220v 50hz 1 Phase |
| 18 | Core Index Motor | Hybrid Stepper Motor With Drive |
| 19 | Online Core Adjustment | Switch Provided |
| 20 | Machine Speed Limit | 10-100 Rpm Max |
| 21 | Shuttles Available | 10mm To 50mm Available On Extra Cost |
| 22 | De Accelaration Turns | Programmable 2-5 Turns |
| 23 | Turns Indication | Display Shown Online |
| 24 | Controller Security | Password Option Provided |
| 25 | Guide Wheels & Spares | Available On Extra Cost |
| 26 | Automatic Stop | After Loading& Winding |
| 27 | Core Positioning | Online Adjustable By Manual |
| 28 | Machine Size | 36x36x55 Inches |
| 29 | Machine Weight | 320 Kgs |
| 30 | Prog Inter Link | Prog No 001 To 499 |
| 30 | Std Tools With Machine | Power Cord, Allen Keys, Spanner & Felt |
| 31 | Switches | Load/Wind/Start/Stop/4 Way Joystick Lever Type |
