1	Total Memory	1 To 499 Different Programs’ Saving Option Provided
2	Turn Set Each Programmes	3000 Max Turns
3	Production Count	Provided
4	Power Fail Save	Counter Will Not Reset
5	Wire Gauge	42 -30 Swg/Slider Type(30-18 Swg Belt Type)
6	Finished Core Outer Diameter	16 -50 Mm - Max
7	Finished Core Inner Diameter	8 Mm-40mm
8	Finished Core Height	5mm-20mm
9	Shuttle Drive Motor	Pmdc Motor
10	Segment Winding	Provided Upto 360 Degrees
11	Winding Pitch Adjust	Provided Switch On Key Board
12	Total Taps	8 Taps Each Prog Provided
13	Display	20x4 Colour Lcd Display
14	Jog Speed 01%-20% Provided	Online Key Provided
15	Wire Loading Speed	Programmable 0%-99% Max-1500 Rpm

16	Winding Speed	Variable By Up/Down Key Max- 1500 Rpm
17	Supply	220v 50hz 1 Phase
18	Core Index Motor	Hybrid Stepper Motor
19	Online Core Adjustment	Switch Provided
20	Machine Speed Limit	Slider -1500rpm- Belt Type-500rpm
21	Shuttles Available	3,4,5,6,7,8,Mm Extra Cost
22	De Accelaration Turns	Programmable 5-25 Turns
23	Turns Indication	Display Shown Online
24	Controller Security	Password Option Provided
25	0.7mm Nylon Sliders	Available On Extra Cost
26	Automatic Stop	After Loading& Winding
27	Core Positioning	Online Adjustable By Keys
28	Machine Size	600x1000x500mm Height
29	Machine Weight	50 Kgs
30	Prog Inter Link	Prog No 001 To 499
30	Std Tools With Machine	Power Cord,Allen Keys,Spanner & Felt & Belts
31	Switches	Load/Wind/Start/Stop/4 Way Joystick Lever Type
