Technical Specifications & Features
| 1 | TOTAL MEMORY | 1 TO 499 DIFFERENT PROGRAMS’ SAVING OPTION PROVIDED |
| 2 | TURN SET EACH PROGRAMMES | 9.999 MAX TURNS |
| 3 | PRODUCTION COUNT | PROVIDED |
| 4 | POWER FAIL SAVE | COUNTER WILL NOT RESET |
| 5 | WIRE GAUGE | 20-10 SWG |
| 6 | FINISHED CORE OUTER DIAMETER | 150-600 MM |
| 7 | FINISHED CORE INNER DIAMETER | 100 MM-500MM |
| 8 | FINISHED CORE HEIGHT | 50MM-200MM |
| 9 | SHUTTLE DRIVE MOTOR | 3 HP AC GEARED MOTOR WITH VFD |
| 10 | SEGMENT WINDING | PROVIDED UPTO 360 DEGREES |
| 11 | WINDING PITCH ADJUST | PROVIDED |
| 12 | TOTAL TAPS | 8 TAPS EACH PROG PROVIDED |
| 13 | DISPLAY | 20X4 COLOUR LCD DISPLAY |
| 14 | JOG SPEED 01%-20% PROVIDED | ONLINE KEY PROVIDED |
| 15 | WIRE LOADING SPEED 120 RPM | PROGRAMMABLE 0%-99% |
| 16 | WINDING SPEED 120 RPM | PROGRAMMABLE 0%-99% |
| 17 | SUPPLY | 220V 50HZ 1 Phase |
| 18 | CORE INDEX MOTOR | HYBRID STEPPER MOTOR WITH DRIVE |
| 19 | ONLINE CORE ADJUSTMENT | SWITCH PROVIDED |
| 20 | MACHINE SPEED LIMIT | 30-60 RPM MAX |
| 21 | SHUTTLES AVAILABLE | 20/30/40/50 MM EXTRA COST |
| 22 | DE ACCELARATION TURNS | PROGRAMMABLE 2-5 TURNS |
| 23 | TURNS INDICATION | DISPLAY SHOWN ONLINE |
| 24 | CONTROLLER SECURITY | PASSWORD OPTION PROVIDED |
| 25 | GUIDE WHEELS & SPARES | AVAILABLE ON EXTRA COST |
| 26 | AUTOMATIC STOP | AFTER LOADING& WINDING |
| 27 | CORE POSITIONING | ONLINE ADJUSTABLE BY MANUAL |
| 28 | MACHINE SIZE | 48x48x60 INCHES |
| 29 | MACHINE WEIGHT | 400 Kgs |
| 30 | PROG INTER LINK | PROG NO 001 TO 499 |
| 30 | STD TOOLS WITH MACHINE | POWER CORD, ALLEN KEYS, SPANNER & FELT |
| 31 | SWITCHES | LOAD/WIND/START/STOP/4 WAY JOYSTICK LEVER TYPE |
