Coils India

1	TOTAL MEMORY	001- 499 PROGRAMS’ STORAGE
2	TOTAL LAYER	1 OR 2 LAYER
3	PRODUCTION COUNTING	PROVIDED
4	POWER FAIL SAVE	COUNTER WILL NOT RESET
5	TAPE WIDTH	16/20MM MM
6	FINISHED CORE OUTER DIA	50-300 MM DIAMETERS
7	FINISHED CORE INNER DIA	40MM-250 MM
8	FINISHED CORE HEIGHT	25MM- 125 MM
9	SHUTTLE DRIVE MOTOR	1 HP AC GEARED MOTOR WITH VFD
10	SEGMENT WINDING	NA
11	TAPE WINDING PITCH ADJUST	PROVIDED ONLINE OPTION
12	SUPPLY	220V 50HZ 1 Phase
13	DISPLAY	20X4 COLOUR LCD DISPLAY
14	JOG SPEED	LOWEST RPM PROGRAMMABLE IN 01%- 10%
15	WIRE LOADING SPEED	PROGRAMMABLE IN 0%-99%
16	WINDING SPEED – 10-100 RPM	VARIABLE BY UP/DOWN KEY- ALSO IN 0%-99%

17	TOTAL TAPS	NA
18	CORE INDEX MOTOR	HYBRID STEPPER MOTOR
19	ONLINE CORE ADJUSTMENT	LH/RH KEYS PROVIDED
20	SHUTTLES AVAILABLE	8,10.12.16 MM
21	TOTAL SWITCHES PROVIDED	START/STOP/LOAD/WIND/4 WAY JOYSTICK SWITCH
22	DE ACCELARATION TURNS	ENDING SLOW TURNS PROGRAMMABLE
23	TURNS INDICATION	ONLINE
24	CONTROLLER SECURITY	PASSWORD OPTION PROVIDED
25	AUTOMATIC STOP	AFTER LOADING AND TAPE WINDING
26	ONLINE INFORMATION ON DISPLAY	LOADING LENGTH/ TOTAL SET TURNS PRESENT COUNTING / ONLINE SPEED - RPM
27	CORE POSITIONING	ONLINE ADJUSTMENT BY LH/RH KEYS
28	MACHINE SIZE- LXWXH	36X36X45 INCHES
29	MACHINE WEIGHT	NET WT-126KGS (AFTER PACKING 160 KG)
30	STANDARD ACCESSORIES	POWER CORD, ALLEN KEY SET, SPANNER, FELTS
