Technical Specifications & Features
| 1 | Total Memory | 1 To 499 Different Programs’ Saving Option Provided |
| 2 | Turn Set Each Programmes | 9.999 Max Turns |
| 3 | Production Count | Provided |
| 4 | Power Fail Save | Counter Will Not Reset |
| 5 | Wire Gauge | 30-20 Swg |
| 6 | Finished Core Outer Diameter | 30-100 Mm |
| 7 | Finished Core Inner Diameter | 12 Mm-80mm |
| 8 | Finished Core Height | 10mm-60mm |
| 9 | Shuttle Drive Motor | Ac Motor With Vfd |
| 10 | Segment Winding | Provided Upto 360 Degrees |
| 11 | Winding Pitch Adjust | Provided Switch On Key Board |
| 12 | Total Taps | 8 Taps Each Prog Provided |
| 13 | Display | 20x4 Colour Lcd Display |
| 14 | Jog Speed 01%-20% Provided | Online Key Provided |
| 15 | Wire Loading Speed 600 Rpm | Programmable 0%-99% |
| 16 | Winding Speed 600 Rpm 0%-99% | Variable By Up/Down Key |
| 17 | Supply | 220v 50hz 1 Phase |
| 18 | Core Index Motor | Hybrid Stepper Motor |
| 19 | Online Core Adjustment | Switch Provided |
| 20 | Machine Speed Limit | Slider -600rpm- Belt Type-300rpm |
| 21 | Shuttles Available | 8 .10.12.16mm Extra Cost |
| 22 | De Accelaration Turns | Programmable 5-25 Turns |
| 23 | Turns Indication | Display Shown Online |
| 24 | Controller Security | Password Option Provided |
| 25 | 0.7mm Nylon Sliders | Available On Extra Cost |
| 26 | Automatic Stop | After Loading& Winding |
| 27 | Core Positioning | Online Adjustable By Manual |
| 28 | Machine Size | 36x36x36 Inches |
| 29 | Machine Weight | 150 Kgs |
| 30 | Prog Inter Link | Prog No 001 To 499 |
| 30 | Std Tools With Machine | Power Cord,Allen Keys,Spanner & Felt & Belts |
| 31 | Switches | Load/Wind/Start/Stop/4 Way Joystick Lever Type |
| 32 | Segment Winding Option | Provided |
