Technical Specifications & Features
| 1 | Memory | 499 Programs’ Storage |
| 2 | Turn Set Each Programmes | 99.999 Max Turns |
| 3 | Production Count | Provided |
| 4 | Power Fail Save | Counter Will Not Reset |
| 5 | Wire Gauge | 30 Swg- 24 Swg - Wire Winding |
| 6 | Core Outer Diameter-Fod | 16- 40mm Diameters |
| 7 | Core Inner Diameter-Fid | 8 Mm-40 Mm |
| 8 | Core Height -Fht | 5mm-20mm |
| 9 | Shuttle Drive Motor | 180v-180w Pmdc Motor With Drive |
| 10 | Brake | 12v Electromagnetic |
| 11 | Winding Pitch Adjust | Provided Online |
| 12 | Controller Unit | Coilsindia-Make |
| 13 | Display | 20x4 Colour Lcd Display |
| 14 | Jog Speed | Online Key Provided |
| 15 | Supply | 220v 50hz 1 Phase |
| 16 | Winding Speed | Variable By Up/Down Key |
| 17 | Total Taps | 8 Taps Each Prog Provided |
| 18 | Core Index Motor | Hybrid Stepper Motor |
| 19 | Online Core Adjustment | Switch Provided |
| 20 | Winding Speed | Slider -500-1500rpm |
| 21 | Shuttles Available | 3/4/5/6/7mm On Extra Cost |
| 22 | De Accelaration Turns | Programmable |
| 23 | Turns Indication | Online |
| 24 | Controller Security | Password Option Provided |
| 25 | 0.5mm Nylon Sliders | Available On Extra Cost |
